FD controller area network (FDCAN) RM0440
1974/2126 RM0440 Rev 4
44.4 FDCAN registers
44.4.1 FDCAN core release register (FDCAN_CREL)
Address offset: 0x0000
Reset value: 0x3214 1218
44.4.2 FDCAN endian register (FDCAN_ENDN)
Address offset: 0x0004
Reset value: 0x8765 4321
Note: The register read must give the reset value to ensure no endiandess issue.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
REL[3:0] STEP[3:0] SUBSTEP[3:0] YEAR[3:0]
rrrrrrrrrrrrrrrr
1514131211109876543210
MON[7:0] DAY[7:0]
rrrrrrrrrrrrrrrr
Bits 31:28 REL[3:0]: 3
Bits 27:24 STEP[3:0]: 2
Bits 23:20 SUBSTEP[3:0]: 1
Bits 19:16 YEAR[3:0]: 4
Bits 15:8 MON[7:0]: 12
Bits 7:0 DAY[7:0]: 18
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
ETV[31:16]
rrrrrrrrrrrrrrrr
1514131211109876543210
ETV[15:0]
rrrrrrrrrrrrrrrr
Bits 31:0 ETV[31:0]: Endianness test value
The endianness test value is 0x8765 4321.
