48.3 Package data register
Base address: 0x1FFF 7500
Address offset: 0x00
Read only = 0xXXXX where X is factory-programmed
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. PKG[4:0]
rrrrr
Bits 15:5 Reserved, must be kept at reset value
Bits 4:0 PKG[4:0]: Package type
00000: LQFP64
00001: WLCSP64
00010: LQFP100 (all devices) and LQFP80 (for category 2 and category 3 devices)
00101: WLCSP81
00111: LQFP128 / UFBGA121
01000: UFQFPN32
01001: LQFP32
01010: UFQFPN48
01011: LQFP48
01100: WLCSP49
01101: UFBGA64
01110: TFBGA100
10001: LQFP80 (for category 4 devices only)
Others: reserved
