VM15 User Manual Description of Display and Symbols
34
Table 6-5. Left Panel Description – STD1
No
Name
Function
Note
1
BATTERY cover
Cover covering BATTERY storage
2
NIBP connector
Connection port for non-invasive blood pressure
measurement
Suntech-
Option
3
ECG connector
Connector to connect ECG
4
EKG connector
Connector to connect EKG
Option
5
SpO2 connector
Connector to measure SpO2
Masimo-Option
6
TEMP 1 connector
Connector for measuring TEMP1
7
ECG OUT connector
Connector to connect ECG OUT
Option
8
RESET
Button for RESET ESN Module
9
TEMP 2 Connection
Connector for measuring TEMP2
Option
10
TEMP 3 Connection
Connector for measuring TEMP3
Option
11
TEMP 4 Connection
Connector for measuring TEMP4
Option
12
ICO Connection
Connector for measuring CO
Option
13
IBP1/2 Connection
Connector for measuring blood pressure
Option
14
IBP3/4 Connection
Connector for measuring blood pressure
Option
15
EtCO2 Connection
Connector for measuring EtCO2
Option
16
qCON Connection
Connector for measuring qCON
Option
17
Multi Gas Connection
Connector for measuring Multi Gas
Option
Note: You can put the option box at any layer of the track.
Note: The standard module box with ECG, SpO2, NIBP, 1TEMP module and 4.3" LCD is called
the Transport Module, and is referred to as TM in this document.
