4-44 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Troubleshooting
No Paper Sensor
1. Enter Service Diagnostics (page 4-11).
2. Use the Up and Down Arrow buttons to select Printer > IOT Diag > DI-2.
The LCD will display DI-2 H 0.
3. Insert a sheet into the tray to check whether the sensor functions properly.
4. Confirm the number shown on the display increases each time the sheet is
inserted.
5. Press the Stop button to stop the test.
DI-5 Regi Sensor
DI-7 Interlock Switch
DI-8 CRUM Y
DI-9 CRUM M
DI-a CRUM C
DI-b CRUM K
Code Component
