Xerox Phaser 6000 Service Manual

A-20 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Reference
K MODE SOLENOID ON 1. ) Remove the Left Side Cover and the
MAIN PAPER TRAY HARNESS GUIDE.
2. Power on the printer, and start up the CE
Diag Tool.
3. Execute the K MODE SOLENOID ON test.
4. Check the K Mode Solenoid movement.
5. Click the Stop button to stop the test.
Test example:
14:14]
Digital Output Mode = ENTRY
[14:14]
K MODE SOLENOID ON = ON
STARTED = K MODE SOLENOID ON
[14:15]
Digital Output Mode = EXIT
Test Procedure
s6000-151
K Mode Solenoid
