Xerox Phaser 6000 Service Manual

Phaser 6000/6010 and WC 6015 MFP Xerox Internal Use Only A-21
Reference
FAN ON (HIGH)
FAN ON (LOW)
1. Power on the printer, and start the CE Diag
Too l.
2. Select the FAN ON (HIGH) or FAN ON
(LOW) tests, and click the OK button.
3. Check that the Fan rotates.
5. Click the Stop button to stop the test.
Test example:
[14:14]
Digital Output Mode = ENTRY
[14:14]
FAN ON (HIGH) = ON
STARTED = FAN ON (HIGH)
[14:15]
Digital Output Mode = EXIT
Test Procedure
s6000-148
