Phaser 6000/6010 and WC 6015 MFP Xerox Internal Use Only 2-7
Theory of Operation
s6000-057
Photoreceptor
: Negative Electric Charge
: Positive Electric Charge
Conductor
(LED Lights)
(LED Lights)
Drum
LPH
Drum Concept
LED Lights
Electrostatic
Latent Image
Electrostatic
Latent Image
Potential On
Drum Surface
Photoreceptor
Conductor
Drum Surface
