B.3 Parameter Table
YASKAWA ELECTRIC SIEP C710616 27G YASKAWA AC Drive A1000 Technical Manual 491
9 Output Frequency Lower Limit Level
10 V = E1-04 (maximum output frequency)
261
B PID Feedback
10 V = 100%
261
C PID Setpoint
10 V = 100%
261
D Frequency Bias
10 V = E1-04 (maximum output frequency)
262
E Motor Temperature (PTC input)
10 V = 100%
262
F Through Mode
Select this setting when the terminal is not used or when using the terminal in the pass-through mode.
262
10 Forward Torque Limit
10 V = Motor rated torque
262
11 Reverse Torque Limit
10 V = Motor rated torque
262
12 Regenerative Torque Limit
10 V = Motor rated torque
262
13
Torque Limit Using Torque Reference/Speed
Control
10 V = Motor rated torque
262
14 Torque Compensation
10 V = Motor rated torque
262
15 General Torque Limit
10 V = Motor rated torque
262
16 Differential PID Feedback
10 V = 100%
262
17 Motor Thermistor (NTC)
10 V = -9°C
0 V = 234°C
Note: This set value is available in models CIMR-A4A0930 and 4A1200.
262
1F Through Mode
Select this setting when the terminal is not used or when using the terminal in the pass-through mode.
262
30 to 32 DriveWorksEZ Analog Input 1 to 3
Output is determined by the function selected using DWEZ.
262
H3 Multi-Function Analog Input Settings
Setting Function Description (For when output is 100%) Page
All Modes
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV
All Modes
To Next Page
