Mechanical & Electrical Installation
2
2.5 Drive Watt Loss
YASKAWA ELECTRIC SIEP C710617 05F YASKAWA AC Drive GA700 Technical Manual 41
Model
Rated Output
Current
A
Carrier Frequency
kHz
Interior Unit Loss
W
Cooling Fin Loss
W
Total Loss
W
2257 257 2 519 1534 2053
2313 313 2 579 1794 2373
2360 360 2 655 2071 2726
2415 - - - - -
◆ 400 V Class
Table 2.3 Drive Watt Loss (Heavy Duty: < 460 V)
Model
Rated Output
Current
A
Carrier Frequency
kHz
Interior Unit Loss
W
Cooling Fin Loss
W
Total Loss
W
4002 1.8 8 38 15 53
4004 3.4 8 42 28 70
4005 4.8 8 46 37 83
4007 5.5 8 48 45 93
4009 7.2 8 37 61 98
4012 9.2 8 46 82 128
4018 14.8 8 65 140 205
4023 18 8 73 150 223
4031 24 8 101 211 312
4038 31 8 119 272 391
4044 39 8 148 354 502
4060 45 8 126 389 515
4075 60 8 165 527 692
4089 75 8 184 617 801
4103 91 8 237 779 1016
4140 112 5 300 956 1256
4168 150 5 486 1274 1760
4208 180 5 446 1432 1878
4250 216 5 558 1464 2022
4296 260 5 692 2061 2753
4371 304 5 824 2346 3170
4389 371 5 777 2212 2989
4453 414 2 963 2696 3659
4568 453 2 1086 3035 4121
4675 605 2 1328 3995 5323
Table 2.4 Drive Watt Loss (Heavy Duty: ≥ 460 V)
Model
Rated Output
Current
A
Carrier Frequency
kHz
Interior Unit Loss
W
Cooling Fin Loss
W
Total Loss
W
4002 1.6 8 38 15 53
4004 2.1 8 39 19 58
4005 3.4 8 43 30 73
4007 4.8 8 46 43 89
