10.10 H: Terminal Functions
564 YASKAWA ELECTRIC SIEP C710617 05F YASKAWA AC Drive GA700 Technical Manual
No.
(Hex.)
Name Description
Default
(Range)
Ref.
H4-08
(0424)
Terminal AM
Signal Level Select
Sets the MFAO terminal AM output signal level.
Note:
Set jumper S5 on the terminal board to the correct position after
changing this parameter.
0 : 0 to 10 Vdc
1 : -10 to +10 Vdc
2 : 4 to 20 mA
0
(0 - 2)
926
H4-20
(0B53)
Analog Power
Monitor 100%
Level
Sets the level at 10 V when U1-08 [Output Power] is set for analog
output.
0.00 kW
(0.00 - 650.00 kW)
927
◆ H5: Modbus Communication
No.
(Hex.)
Name Description
Default
(Range)
Ref.
H5-01
(0425)
Drive Node
Address
Sets the communication slave address for drives.
Note:
• Restart the drive after changing the parameter setting.
• Setting 0 will not let the drive respond to MEMOBUS/Modbus
communications.
1FH
(0 - FFH)
927
H5-02
(0426)
Communication
Speed Selection
Sets the communications speed for MEMOBUS/Modbus
communications.
Note:
Restart the drive after you change the parameter setting.
0 : 1200 bps
1 : 2400 bps
2 : 4800 bps
3 : 9600 bps
4 : 19.2 kbps
5 : 38.4 kbps
6 : 57.6 kbps
7 : 76.8 kbps
8 : 115.2 kbps
3
(0 - 8)
927
H5-03
(0427)
Communication
Parity Selection
Sets the communications parity used for MEMOBUS/Modbus
communications.
Note:
Restart the drive after you change the parameter setting.
0 : No parity
1 : Even parity
2 : Odd parity
0
(0 - 2)
928
H5-04
(0428)
Communication
Error Stop Method
Sets the motor Stopping Method when the drive detects CE
[Modbus Communication Error] issues.
0 : Ramp to Stop
1 : Coast to Stop
2 : Fast Stop (Use C1-09)
3 : Alarm Only
3
(0 - 3)
928
H5-05
(0429)
Comm Fault
Detection Selection
Sets the function that detects CE [Modbus Communication Error]
issues during MEMOBUS/Modbus communications.
0 : Disabled
1 : Enabled
1
(0, 1)
928
