10.13 o: Keypad-Related Settings
588 YASKAWA ELECTRIC SIEP C710617 05F YASKAWA AC Drive GA700 Technical Manual
No.
(Hex.)
Name Description
Default
(Range)
Ref.
o1-50
(11CA)
RUN
Trend Plot 2 Scale
Maximum Value
Sets the maximum value for the vertical axis used to display the
monitor that was set in o1-25 [Custom Monitor 2] as a trend plot.
This parameter is only available with an LCD keypad.
100.0%
(-99.9 - +300.0%)
1017
o1-51
(11CB)
RUN
Trend Plot Time
Scale Setting
Sets the time scale (horizontal axis) to display the trend plot. When
you change this setting, the drive automatically adjusts the data
sampling time. This parameter is only available with an LCD
keypad.
300 s
(1 - 3600 s)
1017
o1-55
(11EE)
RUN
Analog Gauge
Area Selection
Sets the range used to display the monitor set in o1-24 [Custom
Monitor 1] as an analog gauge. This parameter is only available
with an LCD keypad.
0 : +/- Area ( - o1-56 ～ o1-56 )
1 : + Area ( 0 ～ o1-56 )
1
(0, 1)
1017
o1-56
(11EF)
RUN
Analog Gauge
Area Setting
Sets the value used to display the monitor set in o1-24 [Custom
Monitor 1] as an analog meter. This parameter is only available with
an LCD keypad.
100.0%
(0.0 - 100.0%)
1017
◆ o2: Keypad Operation
No.
(Hex.)
Name Description
Default
(Range)
Ref.
o2-01
(0505)
LO/RE Key
Function Selection
Sets the function that lets the drive switch between LOCAL and
REMOTE Modes using the button.
0 : Disabled
1 : Enabled
1
(0, 1)
1017
o2-02
(0506)
STOP Key
Function Selection
Sets the function to stop the drive with the button on the
keypad when the Run command source for the drive is REMOTE
(external) and not assigned to the keypad.
0 : Disabled
1 : Enabled
1
(0, 1)
1018
o2-03
(0507)
User Parameter
Default Value
Sets the function to keep the settings of changed parameters as user
parameter defaults to use during initialization.
0 : No change
1 : Set defaults
2 : Clear all
0
(0 - 2)
1018
o2-04
(0508)
Drive Model
(KVA) Selection
Sets the Drive Model code. Set this parameter after replacing the
control board.
Determined by the
drive
(-)
1019
o2-05
(0509)
Home Mode Freq
Ref Entry Mode
Sets the function that makes it necessary to push the button to
change the frequency reference value with the keypad when in
Drive Mode.
0 : ENTER Key Required
1 : Immediate / MOP-style
0
(0, 1)
1019
o2-06
(050A)
Keypad Disconnect
Detection
Sets the function that stops the drive if you disconnect the keypad
connection cable from the drive or if you damage the cable while
the keypad is the Run command source.
0 : Disabled
1 : Enabled
Determined by o2-
09
(0, 1)
1020
