9.6 Drive Derating
464 YASKAWA ELECTRIC SIEP C710617 05F YASKAWA AC Drive GA700 Technical Manual
Model
Rated Current (A)
Heavy Duty Rating (HD2) Normal Duty Rating (ND2)
2 kHz 4 kHz 6 kHz 8 kHz 10 kHz 12 kHz 2 kHz 4 kHz 6 kHz 8 kHz 10 kHz 12 kHz
4208 156.0 146.6 118.6 90.5 62.4 - 180.0 143.2 106.5 69.7 33.0 -
4250 180.0 169.2 136.8 104.4 72.0 - 240.0 199.4 158.7 118.1 77.4 -
4296 240.0 225.6 182.4 139.2 96.0 - 302.0 252.2 202.3 152.5 102.6 -
4371 302.0 283.9 229.5 175.2 120.8 - 361.0 297.2 233.5 169.7 105.9 -
4389 361.0 339.3 274.4 209.4 144.4 - 414.0 347.6 281.1 214.7 148.3 -
4453 414.0 310.5 - - - - 477.0 312.6 - - - -
4568 477.0 357.8 - - - - 515.0 337.5 - - - -
4675 - - - - - - - - - - - -
◆ Altitude Derating
Install the drive in a location that with an altitude of 1000 m (3281 ft.) or lower.
Derate the output current by 1% for each 100 m (328 ft.) to install the drive in altitudes between 1000 m to 3000
m (3281 ft. to 9843 ft.).
It is not necessary to derate the rated voltage in these conditions:
• Installing the drive at 2000 m (6562 ft.) or lower
• Installing the drive between 2000 m to 3000 m (6562 ft. to 9843 ft.) and grounding the neutral point on the
power supply.
Contact Yaskawa or your nearest sales representative when the drive is not grounded with the neutral network.
