Parameter List
10
10.9 F: Options
YASKAWA ELECTRIC SIEP C710617 05F YASKAWA AC Drive GA700 Technical Manual 533
No.
(Hex.)
Name Description
Default
(Range)
Ref.
F1-37
(03BD)
Encoder 2 Signal
Selection
Sets the number of channels for the signal to the encoder option card
for motor 2.
0 : A Pulse Detection
1 : AB Pulse Detection
0
(0, 1)
826
F1-50
(03D2)
PG-F3 Option
Encoder Type
Sets the type of encoder connected to the PG-F3 option.
0 : EnDat Sin/Cos
1 : EnDat Serial Only
2 : HIPERFACE
0
(0 - 2)
827
F1-51
(03D3)
PG-F3 PGoH
Detection Level
The drive will detect PGoH [Encoder (PG) Hardware Fault] when
the value of this parameter is less than the value of
.
Note:
Set F1-20 = 1 [Encoder 1 PCB Disconnect Detect = Enabled] to
enable this function.
80%
(1 - 100%)
827
F1-52
(03D4)
Serial Encoder
Comm Speed
Sets the communication speed between the PG-F3 option and the
serial encoder.
0 : 1M/9600bps
1 : 500k/19200bps
2 : 1M/38400bps
0
(0 - 2)
827
◆ F2: Analog Input Option
No.
(Hex.)
Name Description
Default
(Range)
Ref.
F2-01
(038F)
Analog Input
Function Selection
Sets the input method for the analog reference used with AI-A3.
0 : 3 Independent Channels
1 : 3 Channels Added Together
0
(0, 1)
827
F2-02
(0368)
RUN
Analog Input
Option Card Gain
Sets the analog reference gain as a percentage when the maximum
output frequency is 100%.
Note:
Set F2-01 = 1 [Analog Input Function Selection = 3 Channels
Added Together] to enable this function.
100.0%
(-999.9 - +999.9%)
829
F2-03
(0369)
RUN
Analog Input
Option Card Bias
Sets the analog reference bias as a percentage when the maximum
output frequency is 100%.
Note:
Set F2-01 = 1 [Analog Input Function Selection = 3 Channels
Added Together] to enable this function.
0.0%
(-999.9 - +999.9%)
829
