Parameter List
10
10.10 H: Terminal Functions
YASKAWA ELECTRIC SIEP C710617 05F YASKAWA AC Drive GA700 Technical Manual 563
Setting Function Description Ref.
1F Not Used
Value for terminals that are not being used or terminals being used in through mode.
923
30 DWEZ Analog
Input 1
Use with DriveWorksEZ. Refer to the DriveWorksEZ online manual for more
information.
923
31 DWEZ Analog
Input 2
Use with DriveWorksEZ. Refer to the DriveWorksEZ online manual for more
information.
923
32 DWEZ Analog
Input 3
Use with DriveWorksEZ. Refer to the DriveWorksEZ online manual for more
information.
923
◆ H4: Analog Outputs
No.
(Hex.)
Name Description
Default
(Range)
Ref.
H4-01
(041D)
Terminal FM
Analog Output
Select
Sets the monitor number to send from MFAO terminal FM.
Set the x-xx part of the Ux-xx [Monitor]. For example, set H4-01 =
102 to monitor U1-02 [Output Frequency].
102
(000 - 999)
925
H4-02
(041E)
RUN
Terminal FM
Analog Output
Gain
Sets the gain of the monitor signal that is sent from MFAO terminal
FM.
Sets the analog signal output level from the terminal FM at 10 V or
20 mA as 100% when an output for monitoring items is 100%.
100.0%
(-999.9 - +999.9%)
925
H4-03
(041F)
RUN
Terminal FM
Analog Output
Bias
Sets the bias of the monitor signal that is sent from MFAO terminal
FM.
Set the level of the analog signal sent from terminal FM at 10 V or
20 mA as 100% when an output for monitoring items is 0%.
0.0%
(-999.9 - +999.9%)
925
H4-04
(0420)
Terminal AM
Analog Output
Select
Sets the monitoring number to be output from the MFAO terminal
AM.
Set the x-xx part of the Ux-xx [Monitor]. For example, set H4-04 to
102 to monitor U1-02 [Output Frequency].
103
(000 - 999)
925
H4-05
(0421)
RUN
Terminal AM
Analog Output
Gain
Sets the gain of the monitor signal that is sent from MFAO terminal
AM.
When an output for monitoring items is 0%, this parameter sets the
analog signal output level from the AM terminal at 10 Vor 20 mA
as 100%.
50.0%
(-999.9 - +999.9%)
926
H4-06
(0422)
RUN
Terminal AM
Analog Output
Bias
Sets the bias of the monitor signal that is sent from MFAO terminal
AM.
Set the level of the analog signal sent from the AM terminal at 10 V
or 20 mA as 100% when an output for monitoring items is 0%.
0.0%
(-999.9 - +999.9%)
926
H4-07
(0423)
Terminal FM
Signal Level Select
Sets the MFAO terminal FM output signal level.
Note:
Set jumper S5 on the terminal board to the correct position after
changing this parameter.
0 : 0 to 10 Vdc
1 : -10 to +10 Vdc
2 : 4 to 20 mA
0
(0 - 2)
926
