10.13 o: Keypad-Related Settings
586 YASKAWA ELECTRIC SIEP C710617 05F YASKAWA AC Drive GA700 Technical Manual
10.13 o: Keypad-Related Settings
◆ o1: Keypad Display
No.
(Hex.)
Name Description
Default
(Range)
Ref.
o1-01
(0500)
RUN
User Monitor
Selection
Set the U monitor for the Drive Mode. This parameter is only
available when you use an LED keypad.
Note:
You cannot select U2 monitor [Fault Trace] or U3 Monitor
[Fault History].
106
(104 - 855)
1011
o1-02
(0501)
RUN
Monitor Selection
at Power-up
Sets the monitor item that the keypad screen shows after energizing
the drive. Refer to “U: Monitors” for information about the monitor
items that the keypad screen can show. This parameter is only
available when using an LED keypad.
1 : Frequency Reference (U1-01)
2 : Direction
3 : Output Frequency (U1-02)
4 : Output Current (U1-03)
5 : User Monitor (o1-01)
1
(1 - 5)
1011
o1-03
(0502)
Frequency Display
Unit Selection
Sets the display units for the frequency reference and output
frequency.
0 : 0.01 Hz
1 : 0.01% (100% = E1-04)
2 : Revolutions Per Minute (RPM)
3 : User Units (o1-10 & o1-11)
Determined by A1-
02
(0 - 3)
1011
o1-04
(0503)
V/f Pattern Display
Unit
Sets the setting unit for parameters that set the V/f pattern
frequency.
0 : Hz
1 : Revolutions Per Minute (RPM)
Determined by A1-
02
(0, 1)
1012
o1-05
(0504)
RUN
LCD Contrast
Adjustment
Sets the contrast of the LCD display on the keypad.
5
(0 - 10)
1013
o1-10
(0520)
User Units
Maximum Value
Sets the value that the drive shows as the maximum output
frequency.
Determined by o1-
03
(1 - 60000)
1013
o1-11
(0521)
User Units
Decimal Position
Sets the number of decimal places for frequency reference and
monitor values.
0 : No Decimal Places (XXXXX)
1 : One Decimal Places (XXXX.X)
2 : Two Decimal Places (XXX.XX)
3 : Three Decimal Places (XX.XXX)
Determined by o1-
03
(0 - 3)
1013
o1-24 to o1-
35
(11AD -
11B8)
RUN
Custom Monitor 1
to 12
Sets a maximum of 12 monitors as user monitors. This parameter is
only available with an LED keypad.
o1-24: 101
o1-25: 102
o1-26: 103
o1-27 to o1-35: 0
(0, 101 - 999)
1013
o1-36
(11B9)
RUN
LCD Backlight
Brightness
Sets the intensity of the LCD keypad backlight.
3
(1 - 5)
1014
o1-37
(11BA)
RUN
LCD Backlight
ON/OFF Selection
Sets the automatic shut off function for the LCD backlight.
0 : OFF
1 : ON
1
(0, 1)
1014
