2.5 Drive Watt Loss
40 YASKAWA ELECTRIC SIEP C710617 05F YASKAWA AC Drive GA700 Technical Manual
2.5 Drive Watt Loss
◆ 200 V Class
Table 2.1 Drive Watt Loss (Heavy Duty)
Model
Rated Output
Current
A
Carrier Frequency
kHz
Interior Unit Loss
W
Cooling Fin Loss
W
Total Loss
W
2004 3.2 8 35 18 53
2006 5 8 37 26 63
2010 8 8 44 43 87
2012 11 8 50 61 111
2018 14 8 47 82 129
2021 17.5 8 56 105 161
2030 25 8 74 174 248
2042 33 8 88 183 271
2056 47 8 112 267 379
2070 60 8 145 373 518
2082 75 8 179 478 657
2110 88 8 155 563 718
2138 115 8 212 680 892
2169 145 5 275 820 1095
2211 180 5 314 991 1305
2257 215 5 398 1252 1650
2313 283 5 502 1643 2145
2360 346 5 582 1978 2560
2415 415 5 644 2359 3003
Table 2.2 Drive Watt Loss (Normal Duty)
Model
Rated Output
Current
A
Carrier Frequency
kHz
Interior Unit Loss
W
Cooling Fin Loss
W
Total Loss
W
2004 3.5 2 35 16 51
2006 6 2 38 25 63
2010 9.6 2 49 46 95
2012 12.2 2 56 62 118
2018 17.5 2 53 88 141
2021 21 2 75 125 200
2030 30 2 95 206 301
2042 42 2 129 227 356
2056 56 2 149 302 451
2070 70 2 177 403 580
2082 82 2 202 467 669
2110 110 2 192 631 823
2138 138 2 269 814 1083
2169 169 2 338 941 1279
2211 211 2 384 1131 1515
