11.8 H: Terminal Functions
YASKAWA ELECTRIC SIEP C710617 05F YASKAWA AC Drive GA700 Technical Manual 889
Note:
• If you use the function to output logical calculation results, you cannot set H2-01 to H2-03 = 1xx [Inverse Output of xx]. If you do, the
drive will detect oPE33 [Digital Output Selection Error ].
• You cannot set 0 [3-Wire Sequence] and 20 to 2F [External Fault] for H2-60, H2-63, and H2-66.
• When you do not use H2-60, H2-63, and H2-66, set them to F. The Through Mode function is not supported.
◆ H2 MFDO Parameters
■ H2-01: Term M1-M2 Function Selection
No.
(Hex.)
Name Description
Default
(Range)
H2-01
(040B)
Term M1-M2
Function Selection
Sets the function for MFDO terminal M1-M2.
0
(0 - 1A7)
Note:
Set this parameter to F when not using the terminal or to use the terminal in through mode.
■ H2-02: Term M3-M4 Function Selection
No.
(Hex.)
Name Description
Default
(Range)
H2-02
(040C)
Term M3-M4
Function Selection
Sets the function for MFDO terminal M3-M4.
1
(0 - 1A7)
Note:
Set this parameter to F when not using the terminal or to use the terminal in through mode.
■ H2-03: Term M5-M6 Function Selection
No.
(Hex.)
Name Description
Default
(Range)
H2-03
(040D)
Term M5-M6
Function Selection
Sets the function for MFDO terminal M5-M6.
2
(0 - 1A7)
Note:
Set this parameter to F when not using the terminal or to use the terminal in through mode.
■ H2-06: Watt Hour Output Unit Selection
No.
(Hex.)
Name Description
Default
(Range)
H2-06
(0437)
Watt Hour Output
Unit Selection
Sets the unit for the output signal when H2-01 to H2-03 = 39 [MFDO
Function Select = Watt Hour Pulse Output].
0
(0 - 4)
This output is input to the Watt hour meter or PLC through a 200 ms pulse signal. This parameter sets the kWh
unit for each pulse output.
Figure 11.90 Example MFDO when Configured for Watt Hours
Note:
• When the power value is a negative value (regenerative state), the drive does not count Watt hours.
• When the control power supply to the drive is operating, the drive will keep the Watt hours. If a momentary power loss causes the drive
to lose control power, the Watt hour count will reset.
