6.7 Auto-Tuning Errors
YASKAWA ELECTRIC SIEP C710617 05F YASKAWA AC Drive GA700 Technical Manual 381
6.7 Auto-Tuning Errors
This table gives information about errors detected during Auto-Tuning. If the drive detects an Auto-Tuning error,
the keypad will show the error and the motor will coast to stop. The drive will not send notification signals for
faults and alarms when Auto-Tuning errors occur.
Two types of Auto-Tuning errors are: Endx and Erx. Endx identifies that Auto-Tuning has successfully completed
with calculation errors. Find and repair the cause of the error and do Auto-Tuning again, or set the motor
parameters manually. You can use the drive in the application if you cannot find the cause of the Endx error.
Erx identifies that Auto-Tuning was not successful. Find and repair the cause of the error and do Auto-Tuning
again.
Code Name Causes Possible Solutions
End1 Excessive Rated Voltage
Setting
The torque reference was more than
20% during Auto-Tuning or the no-load
current that was measured after Auto-
Tuning is more than 80%.
• Make sure that the input motor nameplate data is
correct.
• Do Auto-Tuning again and correctly set the
motor nameplate data.
• If you can uncouple the motor and load, remove
the motor from the machine and do Rotational
Auto-Tuning again.
• If you cannot uncouple the motor and load, use
the results from Auto-Tuning.
Code Name Causes Possible Solutions
End2 Iron Core Saturation
Coefficient
The motor nameplate data entered
during Auto-Tuning is incorrect.
• Make sure that the input motor nameplate data is
correct.
• Do Auto-Tuning again and correctly set the
motor nameplate data.
Auto-Tuning results were not in the
applicable parameter setting range, and
E2-07 or E2-08 [Motor Saturation
Coefficient 2] have temporary values.
• Examine and repair damaged motor wiring.
• If you can uncouple the motor and load, remove
the motor from the machine and do Rotational
Auto-Tuning again.
Code Name Causes Possible Solutions
End3 Rated Current Setting
Alarm
The rated current value is incorrect. Do Auto-Tuning again and set the correct rated
current shown on the motor nameplate.
Code Name Causes Possible Solutions
End4 Adjusted Slip Calculation
Error
The Auto-Tuning results were not in the
applicable parameter setting range.
The motor rated slip that was measured
after Stationary Auto-Tuning was 0.2
Hz or lower.
The motor rated slip that was measured
after compensation with E2-08 [Motor
Saturation Coefficient 2] is not in the
applicable range.
The secondary resistor measurement
results were not in the applicable range.
• Make sure the input motor nameplate data is
correct.
• Do Rotational Auto-Tuning again and correctly
set the motor nameplate data.
• If you cannot uncouple the motor and load, do
Stationary Auto-Tuning 2.
Code Name Causes Possible Solutions
End5 Resistance Tuning Error The Auto-Tuning results of the Line-to-
Line Resistance were not in the
applicable range.
• Make sure that the input motor nameplate data is
correct.
• Examine and repair damaged motor wiring.
Code Name Causes Possible Solutions
End6 Leakage Inductance Alarm The Auto-Tuning results were not in the
applicable parameter setting range.
Make sure that the input motor nameplate data is
correct, and do Auto-Tuning again.
A1-02 [Control Method Selection]
setting is not applicable.
• Examine the value set in A1-02.
• Make sure that the input motor nameplate data is
correct, and do Auto-Tuning again.
