10.16 T: Motor Tuning
YASKAWA ELECTRIC SIEP C710617 05F YASKAWA AC Drive GA700 Technical Manual 595
10.16 T: Motor Tuning
◆ T0: Tuning Mode Selection
No.
(Hex.)
Name Description
Default
(Range)
Ref.
T0-00
(1197)
Tuning Mode
Selection
Sets the type of Auto-Tuning.
0 : Motor Parameter Tuning
1 : Control Tuning
0
(0, 1)
1032
◆ T1: InductionMotor Auto-Tuning
No.
(Hex.)
Name Description
Default
(Range)
Ref.
T1-00
(0700)
Motor 1/Motor 2
Selection
Sets which motor to tune when motor 1/2 switching is enabled. You
can only use the keypad to set this parameter. You cannot use
external input terminals to set it.
Note:
Set H1-xx = 16 [Motor 2 Selection] ON to set this parameter.
The keypad will not show this parameter when H1-xx = 16 is
OFF.
1 : Motor 1 (sets E1-oo, E2-oo)
2 : Motor 2 (sets E3-oo, E4-oo)
1
(1, 2)
1032
T1-01
(0701)
Auto-Tuning Mode
Selection
Sets the type of Auto-Tuning.
0 : Rotational Auto-Tuning
1 : Stationary Auto-Tuning 1
2 : Stationary Line-Line Resistance
Determined by A1-
02
(Determined by
A1-02)
1033
T1-02
(0702)
Motor Rated Power
Sets the rated output power (kW) of the motor.
Determined by o2-
04 and C6-01
(0.00 - 650.00 kW)
1033
T1-03
(0703)
Motor Rated
Voltage
Sets the rated voltage (V) of the motor. Enter the base speed voltage
for constant output motors.
Determined by o2-
04 and C6-01
(200 V Class: 0.0 -
255.5 V, 400 V
Class: 0.0 - 511.0
V)
1033
T1-04
(0704)
Motor Rated
Current
Sets the rated current (A) of the motor.
Determined by o2-
04
(10% to 200% of
the drive rated
current)
1033
T1-05
(0705)
Motor Base
Frequency
Sets the base frequency (Hz) of the motor.
50.0 Hz
(0.0 - 590.0 Hz)
1033
T1-06
(0706)
Number of Motor
Poles
Sets the number of motor poles.
4
(2 - 48)
1034
T1-07
(0707)
Motor Base Speed
Sets the motor base speed for Auto-Tuning (min
-1
(r/min)).
1450 min
-1
(r/min)
(0 - 35400 min
-1
(r/
min))
1034
T1-08
(0708)
Encoder Pulse
Count (PPR)
Sets the number of PG (pulse generator, encoder) pulses.
1024 ppr
(0 - 60,000 ppr)
1034
T1-09
(0709)
Motor No-Load
Current
Sets the no-load current of the motor.
-
(0A - T1-04; max.
of 2999.9)
1034
T1-10
(070A)
Motor Rated Slip
Frequency
Sets the motor rated slip.
-
(0.000 - 20.000
Hz)
1034
