Parameter Details
11
11.3 b: Application
YASKAWA ELECTRIC SIEP C710617 05F YASKAWA AC Drive GA700 Technical Manual 697
11.3 b: Application
b parameters set the following functions.
• Frequency reference source/Run command source
• Stopping method settings
• DC Injection Braking
• Speed Search
• Timer Function
• PID control
• Dwell function
• Droop control
• Energy Savings Control
• Zero Servo Control
◆ b1: Operation Mode Selection
b1 parameters set the operation mode for the drive.
■ b1-01: Frequency Reference Selection 1
No.
(Hex.)
Name Description
Default
(Range)
b1-01
(0180)
Frequency Reference
Selection 1
Sets the input method for the frequency reference.
1
(0 - 4)
Note:
• Push on the keypad to set the input mode to LOCAL and enter the frequency reference from the keypad.
• When the drive receives a Run command when the frequency reference is 0 Hz or less than the E1-09 [Minimum Output Frequency]
value, on the keypad will flash. Check the setting for the frequency reference input and enter a value more than or equal to the
E1-09 value.
0 : Keypad
Use the keypad to enter the frequency reference.
Use and on the keypad to change the frequency reference.
1 : Analog Input
Use MFAI terminals A1, A2, and A3 to input an analog frequency reference with a voltage or current input signal.
• Voltage Input
Refer to Table 11.22 to use a voltage signal input to one of the MFAI terminals.
Table 11.22 Frequency Reference Voltage Input
Termi
nal
Terminal Signal
Level
Parameter Settings
Note
Signal Level
Selection
Function
Selection
Gain Bias
A1 0 - 10 V H3-01 = 0 H3-02 = 0
[Frequency
Reference]
H3-03 H3-04 Set DIP switch S1-1 to
“V” for voltage input.
-10 - 10 V H3-01 = 1
A2 0 - 10 V H3-09 = 0 H3-10 = 0
[Frequency
Reference]
H3-11 H3-12 Set DIP switch S1-2 to
“V” for voltage input.
-10 - 10 V H3-09 = 1
A3 0 - 10 V H3-05 = 0 H3-06 = 0
[Frequency
Reference]
H3-07 H3-08 Set DIP switch S1-3 to
“V” for voltage input.
Set DIP switch S4 to
“AI” for analog input.
-10 - 10 V H3-05 = 1
To Next Page
