1.3 Features and Advantages of Control Methods
26 YASKAWA ELECTRIC SIEP C710617 05F YASKAWA AC Drive GA700 Technical Manual
1.3 Features and Advantages of Control Methods
This drive has 9 available control methods from which to select for different applications. Table 1.5, Table 1.6 and
Table 1.7 gives information about the features of each control method.
Table 1.5 V/f and CL-V/f Features and Advantages of Control Methods
Control Method
Selection
Open Loop V/f Control
(V/f)
Closed Loop V/f Control
(CL-V/f)
Notes
Controlled Motor Induction Motor -
Parameter Settings A1-02 = 0 A1-02 = 1 -
Basic Control V/f
Closed loop V/f control with
speed correction
-
Main Applications
General-purpose variable speed
control to connect more than one
motor to one drive.
High-precision speed control with
encoders on machines
-
PG Option Card Not necessary Necessary (PG-B3 or PG-X3) -
Maximum Output
Frequency
590 Hz 400 Hz -
Speed Control Range 1:40 1:40
This is the range of variable control.
When you connect and operate motors in
this method, think about the increase in
motor temperature.
Starting Torque 150% / 3 Hz 150% / 3 Hz
This is the motor torque that the drive can
supply at low speed during start-up and
the related output frequency (rotation
speed).
You must think about drive capacity when
a large quantity of torque is necessary at
low speed.
Auto-Tuning
*1
Rotational and Line-to-Line
Resistance (usually not necessary)
Rotational and Line-to-Line
Resistance (usually not necessary)
Automatically tunes electrical motor
parameters.
Torque Limits
*1
No No
Controls maximum motor torque to
prevent damage to machines and loads.
Torque Control
*1
No No
Directly controls motor torque to control
tension and other parameters.
Droop Control
*1
No No
Sets load torque slip for motors.
Distributes motor loads.
Zero Servo Control
*1
No No
Locks servos without an external position
controller to prevent movement caused by
external force.
Speed Search
*1
Yes -
Immediately estimates (or detects) motor
speed and direction when coasting to a
stop to quickly start-up the drive without
stopping the motor.
Automatic Energy-
saving Control
*1
Yes Yes
Automatically adjusts the voltage applied
to motors to maximize motor efficiency
for all load sizes.
High Slip Braking
(HSB)
*1
Yes Yes
Increases motor loss to let the motor
decelerate faster than usual without a
braking resistor. Motor characteristics
have an effect on this function.
Feed Forward Control
*1
No No
Compensates effects of the system inertia
to increase the speed precision when the
load changes.
KEB Ride-Thru
Function
*1
Yes Yes
Quickly and safely stops the motor during
power loss and automatically starts
operation at the previous speed when
restores power without coasting the motor.
