Parameter List
10
10.17 U: Monitors
YASKAWA ELECTRIC SIEP C710617 05F YASKAWA AC Drive GA700 Technical Manual 601
No.
(Hex.)
Name Description
MFAO Signal
Level
Ref.
U1-17
(0058)
DI-A3 Input Status
Shows the reference value input from DI-A3 option.
Shows the input signal for DI-A3 in hexadecimal as set in F3-01
[Digital Input Function Selection].
3FFFF: Set (1 bit) + Sign (1 bit) + 16 bit
No signal output
available
-
U1-18
(0061)
oPE Fault
Parameter
Shows the parameter number that caused the oPE02 [Parameter
Range Setting Error] or oPE08 [Parameter Selection Error].
No signal output
available
-
U1-19
(0066)
MEMOBUS/
Modbus Error
Code
Shows the contents of the MEMOBUS/Modbus communication
error where 1 = (error) and 0 = (no error).
For example, U1-19 shows 00000001 when a CRC error occurs.
bit 0 : CRC Error
bit 1 : Data Length Error
bit 2 : Not used (normal value of 0).
bit 3 : Parity Error
bit 4 : Overrun Error
bit 5 : Framing Error
bit 6 : Timed Out
bit 7 : Not used (normal value of 0).
No signal output
available
-
U1-21
(0077)
AI-A3 Term V1
Level
Shows the analog reference of terminal V1 on analog input option
card AI-A3.
Unit: 0.1%
10 V = 100% (-10
V to +10 V)
-
U1-22
(072A)
AI-A3 Term V2
Level
Shows the analog reference of terminal V2 on analog input option
card AI-A3.
Unit: 0.1%
10 V = 100% (-10
V to +10 V)
-
U1-23
(072B)
AI-A3 Term V3
Level
Shows the analog reference of terminal V3 on analog input option
card AI-A3.
Unit: 0.1%
10 V = 100% (-10
V to +10 V)
-
U1-24
(007D)
Input Pulse
Monitor
Shows the frequency to pulse train input terminal RP.
Unit: 1 Hz
Determined by H6-
02
-
U1-25
(004D)
SoftwareNumber
Flash
Shows the FLASH ID.
No signal output
available
-
U1-26
(005B)
SoftwareNumber
ROM
Shows the ROM ID.
No signal output
available
-
U1-50
(1199)
Expert
Virtual Analog
Input
Shows the virtual analog input value.
Determined by H7-
40
-
U1-91
(154E)
Expert
Output Voltage
Shows the drive internal output voltage reference.
Unit: 0.1 V
200 V class: 10 V
= 200 Vrms
400 V class: 10 V
= 400 Vrms
-
U2: Fault Trace
No.
(Hex.)
Name Description
MFAO Signal
Level
Ref.
U2-01
(0080)
Current Fault
Shows the fault that the drive has when viewing the monitor.
No signal output
available
-
U2-02
(0081)
Previous Fault
Shows the fault that occurred most recently.
No signal output
available
-
V/f
CL-V/f
OLV
CLV
AOLV
OLV/PM OLV/PM
AOLV/PM
CLV/PM
EZOLV
V/f
CL-V/f
OLV
CLV
AOLV
OLV/PM OLV/PM
AOLV/PM
CLV/PM
EZOLV
V/f
CL-V/f
OLV
CLV
AOLV
OLV/PM OLV/PM
AOLV/PM
CLV/PM
EZOLV
V/f
CL-V/f
OLV
CLV
AOLV
OLV/PM OLV/PM
AOLV/PM
CLV/PM
EZOLV
V/f
CL-V/f
OLV
CLV
AOLV
OLV/PM OLV/PM
AOLV/PM
CLV/PM
EZOLV
V/f
CL-V/f
OLV
CLV
AOLV
OLV/PM OLV/PM
AOLV/PM
CLV/PM
EZOLV
V/f
CL-V/f
OLV
CLV
AOLV
OLV/PM OLV/PM
AOLV/PM
CLV/PM
EZOLV
V/f
CL-V/f
OLV
CLV
AOLV
OLV/PM OLV/PM
AOLV/PM
CLV/PM
EZOLV
V/f
CL-V/f
OLV
CLV
AOLV
OLV/PM OLV/PM
AOLV/PM
CLV/PM
EZOLV
V/f
CL-V/f
OLV
CLV
AOLV
OLV/PM OLV/PM
AOLV/PM
CLV/PM
EZOLV
V/f
CL-V/f
OLV
CLV
AOLV
OLV/PM OLV/PM
AOLV/PM
CLV/PM
EZOLV
V/f
CL-V/f
OLV
CLV
AOLV
OLV/PM OLV/PM
AOLV/PM
CLV/PM
EZOLV
V/f
CL-V/f
OLV
CLV
AOLV
OLV/PM OLV/PM
AOLV/PM
CLV/PM
EZOLV
