Parameter List
10
10.13 o: Keypad-Related Settings
YASKAWA ELECTRIC SIEP C710617 05F YASKAWA AC Drive GA700 Technical Manual 587
No.
(Hex.)
Name Description
Default
(Range)
Ref.
o1-38
(11BB)
RUN
LCD Backlight
Off-Delay
Sets the time until the LCD backlight automatically turns off.
60 s
(10 - 300 s)
1014
o1-39
(11BC)
RUN
Show Initial Setup
Screen
Sets the function to show the LCD keypad initial setup screen each
time the drive is energized. This parameter is only available when
using an LCD keypad.
0 : No
1 : Yes
1
(0, 1)
1014
o1-40
(11BD)
RUN
Home Screen
Display Selection
Sets the monitor display mode for the Home screen. This parameter
is only available when using an LCD keypad.
0 : Custom Monitor
1 : Bar Graph
2 : Analog Gauge
3 : Trend Plot
0
(0 - 3)
1015
o1-41
(11C1)
RUN
1st Monitor Area
Selection
Sets the horizontal axis used to show the monitor that was set in o1-
24 [Custom Monitor 1] as a bar graph. This parameter is only
available with an LCD keypad.
0 : +/- Area ( - o1-42 ～ o1-42 )
1 : + Area ( 0 ～ o1-42 )
2 : - Area ( - o1-42 ～ 0 )
0
(0 - 2)
1015
o1-42
(11C2)
RUN
1st Monitor Area
Setting
Sets the horizontal axis value used to display the monitor that was
set in o1-24 [Custom Monitor 1] as a bar graph. This parameter is
only available with an LCD keypad.
100.0%
(0.0 - 100.0%)
1015
o1-43
(11C3)
RUN
2nd Monitor Area
Selection
Sets the horizontal axis used to show the monitor that was set in o1-
25 as a bar graph. This parameter is only available with an LCD
keypad.
0 : +/- Area ( - o1-44 ～ o1-44 )
1 : + Area ( 0 ～ o1-44 )
2 : - Area ( - o1-44 ～ 0 )
0
(0 - 2)
1015
o1-44
(11C4)
RUN
2nd Monitor Area
Setting
Sets the horizontal axis value used to display the monitor that was
set in o1-25 [Custom Monitor 2] as a bar graph. This parameter is
only available with an LCD keypad.
100.0%
(0.0 - 100.0%)
1016
o1-45
(11C5)
RUN
3rd Monitor Area
Selection
Sets the horizontal axis used to show the monitor that was set in o1-
26 as a bar graph. This parameter is only available with an LCD
keypad.
0 : +/- Area ( - o1-46 ～ o1-46 )
1 : + Area ( 0 ～ o1-46 )
2 : - Area ( - o1-46 ～ 0 )
0
(0 - 2)
1016
o1-46
(11C6)
RUN
3rd Monitor Area
Setting
Sets the horizontal axis value used to display the monitor that was
set in o1-26 [Custom Monitor 3] as a bar graph. This parameter is
only available with an LCD keypad.
100.0%
(0.0 - 100.0%)
1016
o1-47
(11C7)
RUN
Trend Plot 1 Scale
Minimum Value
Sets the minimum value for the vertical axis used to display the
monitor that was set in o1-24[Custom Monitor 1] as a trend plot.
This parameter is only available with an LCD keypad.
100%
(-300 - +300%)
1016
o1-48
(11C8)
RUN
Trend Plot 1 Scale
Maximum Value
Sets the maximum value for the vertical axis used to display the
monitor that was set in o1-24 o1-24 [Custom Monitor 1] as a trend
plot. This parameter is only available with an LCD keypad.
100.0%
(-99.9 - +300.0%)
1016
o1-49
(11C9)
RUN
Trend Plot 2 Scale
Minimum Value
Sets the minimum value for the vertical axis used to display the
monitor that was set in o1-25[Custom Monitor 2] as a trend plot.
This parameter is only available with an LCD keypad.
100%
(-300 - +300%)
1016
