11.11 o: Keypad-Related Settings
1012 YASKAWA ELECTRIC SIEP C710617 05F YASKAWA AC Drive GA700 Technical Manual
Note:
When you change ths parameter, these monitor and parameter units also change:
• U1-01 [Freq Reference]
• U1-02 [Output Frequency]
• U1-05 [Motor Speed]
• U1-16 [SFS Output Frequency]
• d1-01 to d1-17 [Reference 1 to 17]
0 : 0.01 Hz
1 : 0.01% (100% = E1-04)
The maximum output frequency is 100%.
2 : Revolutions Per Minute (RPM)
The drive uses the maximum output frequency and number of motor poles calculate this value automatically.
Note:
When you use this setting, make sure that you set the number of motor poles in these parameters:
• E2-04 [Motor Pole Count]
• E4-04 [Motor 2 Motor Poles]
• E5-04 [PM Motor Pole Count]
• E9-08 [Number of Poles]
3 : User Units (o1-10 & o1-11)
Uses o1-10 and o1-11 to set the unit of measure. The value of parameter o1-10 is the value when you remove the
decimal point from the maximum output frequency. Parameter o1-11 is to the number of digits after the decimal
point in the maximum output frequency.
To show a maximum output frequency of 100.00, set the parameters to these values:
• o1-10 = 10000
• o1-11 = 2 [User Units Decimal Position = 2 Dec (XXX.XX)]
■ o1-04: V/f Pattern Display Unit
No.
(Hex.)
Name Description
Default
(Range)
o1-04
(0503)
V/f Pattern Display
Unit
Sets the setting unit for parameters that set the V/f pattern frequency.
Determined by A1-02
(0, 1)
Note:
• Select the setting unit of these parameters for motor 1:
–E1-04 [Maximum Output Frequency]
–E1-06 [Base Frequency]
–E1-07 [Mid Point A Frequency]
–E1-09 [Minimum Output Frequency]
–E1-11 [Mid Point B Frequency]
–E9-02 [Motor Max Revolutions]
–E9-04 [Motor Rated Frequency]
• Select the setting unit of these parameters for motor 2:
–E3-04 [Motor 2 Maximum Output Frequency]
–E3-06 [Motor 2 Base Frequency]
–E3-07 [Motor 2 Mid Point A Frequency]
–E3-09 [Motor 2 Minimum Output Frequency]
–E3-11 [Motor 2 Mid Point B Frequency]
0 : Hz
1 : Revolutions Per Minute (RPM)
Set the number of motor poles in these parameters:
• E2-04 [Motor Pole Count]
• E4-04 [Motor 2 Motor Poles]
• E5-04 [PM Motor Pole Count]
• E9-08 [Motor Pole Count]
