11.8 H: Terminal Functions
YASKAWA ELECTRIC SIEP C710617 05F YASKAWA AC Drive GA700 Technical Manual 925
Terminal FM outputs the analog signal when the monitor item that you set in H4-01 [MFAO Terminal FM
Monitor Select] is 100%.
2. Adjust H4-02 and monitor the meter scale connected to terminal FM.
3. Show H4-03 [FM Analog Output Bias] on the keypad.
The analog signal at the time when the monitor item selected with H4-01 is 0% is output from terminal FM.
4. Adjust H4-03 while referencing the meter scale connected to terminal FM.
Calibrate Terminal AM
Stop the drive to calibrate meters. Use this procedure to calibrate:
1. Show H4-05 [AM Analog Output Gain] on the keypad.
Terminal AM outputs the analog signal when the monitor item that you set in H4-04 [MFAO Terminal AM
Monitor Select] is 100%.
2. Adjust H4-05 and monitor the meter scale connected to terminal AM.
3. Show H4-06 [AM Analog Output Bias] on the keypad.
Terminal AM outputs the analog signal when the monitor item that you set in H4-04 [MFAO Terminal AM
Monitor Select] is 0%.
4. Adjust H4-03 and monitor the meter scale connected to terminal FM.
■ H4-01: Terminal FM Analog Output Select
No.
(Hex.)
Name Description
Default
(Range)
H4-01
(041D)
Terminal FM Analog
Output Select
Sets the monitor number to send from MFAO terminal FM.
102
(000 - 999)
Set the x-xx part of the Ux-xx [Monitor]. For example, set H4-01 to 102 to monitor U1-02 [Output Frequency].
Note:
• The configurable monitor changes when the control method changes.
• To use in through mode, set this parameter to 000 or 031. You can set the terminal FM output level from the PLC through MEMOBUS/
Modbus communications or the communication option.
■ H4-02: Terminal FM Analog Output Gain
No.
(Hex.)
Name Description
Default
(Range)
H4-02
(041E)
RUN
Terminal FM Analog
Output Gain
Sets the gain of the monitor signal that is sent from MFAO terminal FM.
100.0%
(-999.9 - +999.9%)
The analog signal output from the FM terminal is a maximum of ±10 V (or 20 mA). Select the signal level with
H4-07 [Terminal FM Signal Level Select].
■ H4-03: Terminal FM Analog Output Bias
No.
(Hex.)
Name Description
Default
(Range)
H4-03
(041F)
RUN
Terminal FM Analog
Output Bias
Sets the bias of the monitor signal that is sent from MFAO terminal FM.
0.0%
(-999.9 - +999.9%)
The analog signal output from the FM terminal is a maximum of ±10 V (or 20 mA). Select the signal level with
H4-07 [Terminal FM Signal Level Select].
■ H4-04: Terminal AM Analog Output Select
No.
(Hex.)
Name Description
Default
(Range)
H4-04
(0420)
Terminal AM Analog
Output Select
Sets the monitoring number to be output from the MFAO terminal AM.
103
(000 - 999)
Set the x-xx part of the Ux-xx [Monitor]. For example, set H4-04 to 102 to monitor U1-02 [Output Frequency].
