Specifications
9
9.6 Drive Derating
YASKAWA ELECTRIC SIEP C710617 05F YASKAWA AC Drive GA700 Technical Manual 463
Model
Rated Current (A)
Heavy Duty Rating (HD1) Normal Duty Rating (ND1)
2 kHz 4 kHz 6 kHz 8 kHz 10 kHz 12 kHz 2 kHz 4 kHz 6 kHz 8 kHz 10 kHz 12 kHz
4012 9.2 9.2 8.7 7.0 5.4 3.8 11.9 10.3 8.6 7.0 5.4 3.8
4018 14.8 14.8 14.0 11.4 8.9 6.3 17.5 16.5 14.0 11.4 8.9 6.3
4023 18.0 18.0 17.0 13.9 10.8 7.7 23.4 20.4 17.3 14.1 11.0 7.8
4031 24.0 24.0 22.6 18.4 14.1 9.9 31.0 26.8 22.6 18.3 14.1 9.9
4038 31.0 31.0 29.2 23.9 18.6 13.3 38.0 34.5 29.2 23.9 18.6 13.3
4044 39.0 39.0 36.8 30.1 23.4 16.7 44.0 41.6 35.5 29.5 23.4 17.3
4060 45.0 45.0 42.1 33.3 24.4 15.6 59.6 50.8 42.0 33.2 24.4 15.6
4075 60.0 60.0 56.6 46.3 36.0 25.7 74.9 70.2 59.3 48.4 37.5 26.5
4089 75.0 75.0 70.7 57.9 45.0 32.1 89.2 84.5 71.5 58.6 45.6 32.7
4103 91.0 91.0 85.8 70.2 54.6 39.0 103.0 100.5 85.2 69.9 54.6 39.3
4140 112.0 105.3 85.1 65.0 44.8 - 140.0 114.1 88.1 62.0 36.0 -
4168 150.0 141.0 114.0 87.0 60.0 - 168.0 141.8 115.6 89.5 63.3 -
4208 180.0 169.2 136.8 104.4 72.0 - 208.0 165.5 123.1 80.6 38.1 -
4250 216.0 203.0 164.2 125.3 86.4 - 250.0 207.7 165.3 123.0 80.6 -
4296 260.0 244.4 197.6 150.8 104.0 - 296.0 247.1 198.3 149.4 100.6 -
4371 304.0 285.8 231.0 176.3 121.6 - 371.0 305.3 239.7 174.0 108.3 -
4389 371.0 348.7 282.0 215.2 148.4 - 389.0 327.5 265.7 203.8 142.0 -
4453 389.0 292.5 - - - - 453.0 296.7 - - - -
4568 453.0 340.7 - - - - 568.0 372.0 - - - -
4675 605.0 455.0 - - - - 675.0 455.0 - - - -
Table 9.18 AOLV/PM Carrier Frequency and Rated Current Derating (≥ 460 V)
Model
Rated Current (A)
Heavy Duty Rating (HD2) Normal Duty Rating (ND2)
2 kHz 4 kHz 6 kHz 8 kHz 10 kHz 12 kHz 2 kHz 4 kHz 6 kHz 8 kHz 10 kHz 12 kHz
4002 2.1 1.8 1.5 1.2 0.9 0.6 2.1 1.9 1.7 1.6 1.4 1.2
4004 2.8 2.4 2.0 1.5 1.1 0.6 3.0 2.7 2.4 2.1 1.8 1.5
4005 4.3 3.8 3.2 2.7 2.2 1.6 4.8 4.5 4.2 3.8 3.5 3.2
4007 6.2 5.4 4.5 3.7 2.8 2.0 6.9 6.0 5.0 4.1 3.2 2.2
4009 8.6 7.6 6.6 5.6 4.6 3.6 7.6 6.7 5.8 5.0 4.1 3.2
4012 9.8 8.5 7.2 5.8 4.5 3.1 11.0 9.5 8.0 6.5 5.0 3.5
4018 14.1 12.3 10.4 8.5 6.6 4.7 15.2 13.2 11.2 9.1 7.1 5.1
4023 18.0 15.6 13.2 10.8 8.4 6.0 21.0 18.3 15.5 12.7 9.9 7.0
4031 27.2 23.5 19.8 16.1 12.4 8.7 27.0 23.3 19.6 16.0 12.3 8.6
4038 34.7 30.1 25.5 20.8 16.2 11.6 34.0 30.9 26.2 21.4 16.6 11.9
4044 34.0 34.0 32.1 26.2 20.4 14.6 40.0 37.8 32.3 26.8 21.3 15.8
4060 40.0 40.0 37.4 29.6 21.7 13.9 52.0 44.3 36.7 29.0 21.3 13.6
4075 52.0 52.0 49.0 40.1 31.2 22.3 65.0 60.9 51.4 42.0 32.5 23.0
4089 65.0 65.0 61.3 50.1 39.0 27.9 77.0 72.9 61.7 50.6 39.4 28.2
4103 77.0 77.0 72.6 59.4 46.2 33.0 96.0 93.6 79.4 65.1 50.9 36.6
4140 96.0 90.2 73.0 55.7 38.4 - 124.0 101.1 78.0 54.9 31.9 -
4168 124.0 116.6 94.2 71.9 49.6 - 156.0 131.7 107.4 83.1 58.8 -
