Mechanical & Electrical
Installation
2
2.5 Drive Watt Loss
YASKAWA ELECTRIC SIEP C710617 05F YASKAWA AC Drive GA700 Technical Manual 43
Model
Rated Output
Current
A
Carrier Frequency
kHz
Interior Unit Loss
W
Cooling Fin Loss
W
Total Loss
W
4250 250 2 686 1738 2424
4296 296 2 805 2155 2960
4371 371 2 1022 2553 3575
4389 389 2 867 2393 3260
4453 453 2 1086 3035 4121
4568 568 2 1429 3989 5418
4675 675 2 1526 4572 6098
Table 2.6 Drive Watt Loss (Normal Duty: ≥ 460 V)
Model
Rated Output
Current
A
Carrier Frequency
kHz
Interior Unit Loss
W
Cooling Fin Loss
W
Total Loss
W
4002 2.1 2 39 16 55
4004 3 2 42 25 67
4005 4.8 2 45 28 73
4007 6.9 2 50 42 92
4009 7.6 2 35 49 84
4012 11 2 49 76 125
4018 14 2 64 112 176
4023 21 2 87 158 245
4031 27 2 109 188 297
4038 34 2 116 234 350
4044 40 2 137 296 433
4060 52 2 133 379 512
4075 65 2 156 450 606
4089 77 2 180 569 749
4103 96 2 229 698 927
4140 124 2 334 982 1316
4168 156 2 481 1199 1680
4208 180 2 429 1275 1704
4250 240 2 648 1643 2291
4296 302 2 817 2257 3074
4371 361 2 975 2561 3536
4389 414 2 873 2422 3295
4453 477 2 1183 3329 4512
4568 515 2 1320 3697 5017
4675 - - - - -
