Mechanical & Electrical
Installation
2
2.12 Main Circuit Wiring
YASKAWA ELECTRIC SIEP C710617 05F YASKAWA AC Drive GA700 Technical Manual 77
Model Figure
4060 Figure 2.74
2110 Figure 2.75
4075 Figure 2.76
4089 Figure 2.77
2138, 4103 Figure 2.78
2169, 2211, 4140, 4168 Figure 2.79
2257, 2313, 4208 - 4296 Figure 2.80
2360, 2415, 4371, 4389 Figure 2.81
4453 - 4675 Figure 2.82
Figure 2.70 Configuration of Main Circuit Terminal Block
Figure 2.71 Configuration of Main Circuit Terminal Block
