2.12 Main Circuit Wiring
90 YASKAWA ELECTRIC SIEP C710617 05F YASKAWA AC Drive GA700 Technical Manual
Model Terminals
Recommended
Gauge
mm
2
Applicable
Gauge
(IP20
Applicable
Gauge
*1
)
mm
2
Wire
Stripping
Length
*2
mm
Terminal Screw
Tightening
Torque
N∙m (lb.∙in.)
Size Shape
4031
R/L1, S/L2, T/L3 10
2.5 - 25
(10 - 25)
18 M5 Slotted (-)
2.3 - 2.5
(19.8 - 22)
*3
U/T1, V/T2, W/T3 6
2.5 - 16
(6 - 16)
18 M5 Slotted (-)
2.3 - 2.5
(19.8 - 22)
*3
-, +1, +2 10
2.5 - 35
(10 - 35)
20 M6
Hex socket cap
(WAF: 5 mm)
5 - 5.5
(45 - 49)
B1, B2 2.5
2.5 - 10
(2.5 - 10)
10 M4 Slotted (-)
1.5 - 1.7
(13.5 - 15)
10
6 - 16
(-)
- M6
Phillips/slotted
combo
5.4 - 6.0
(47.8 - 53.1)
4038
R/L1, S/L2, T/L3 10
2.5 - 25
(10 - 25)
18 M5 Slotted (-)
2.3 - 2.5
(19.8 - 22)
*3
U/T1, V/T2, W/T3 6
2.5 - 16
(6 - 16)
18 M5 Slotted (-)
2.3 - 2.5
(19.8 - 22)
*3
-, +1, +2 16
2.5 - 35
(10 - 35)
20 M6
Hex socket cap
(WAF: 5 mm)
5 - 5.5
(45 - 49)
B1, B2 4
2.5 - 10
(2.5 - 10)
10 M4 Slotted (-)
1.5 - 1.7
(13.5 - 15)
10
6 - 16
(-)
- M6
Phillips/slotted
combo
5.4 - 6.0
(47.8 - 53.1)
4044
R/L1, S/L2, T/L3 16
2.5 - 16
(4 - 16)
18 M5 Slotted (-)
2.3 - 2.5
(19.8 - 22)
*3
U/T1, V/T2, W/T3 10
2.5 - 10
(6 - 10)
18 M5 Slotted (-)
2.3 - 2.5
(19.8 - 22)
*3
-, +1, +2 25
2.5 - 25
(6 - 25)
18 M5 Slotted (-)
2.3 - 2.5
(19.8 - 22)
*3
B1, B2 6
2.5 - 6
(2.5 - 6)
10 M4 Slotted (-)
1.5 - 1.7
(13.5 - 15)
16
10 - 25
(-)
- M6
Phillips/slotted
combo
5.4 - 6.0
(47.8 - 53.1)
4060
R/L1, S/L2, T/L3 16
2.5 - 16
(4 - 16)
18 M5 Slotted (-)
2.3 - 2.5
(19.8 - 22)
*3
U/T1, V/T2, W/T3 16
2.5 - 16
(6 - 16)
18 M5 Slotted (-)
2.3 - 2.5
(19.8 - 22)
*3
-, +1 25
2.5 - 25
(6 - 25)
18 M5 Slotted (-)
2.3 - 2.5
(19.8 - 22)
*3
B1, B2 10
2.5 - 10
(2.5 - 10)
10 M4 Slotted (-)
1.5 - 1.7
(13.5 - 15)
16
10 - 25
(-)
- M6
Phillips/slotted
combo
5.4 - 6.0
(47.8 - 53.1)
