YASKAWA GA700 - Page 93

Mechanical & Electrical Installation
2
2.12 Main Circuit Wiring
YASKAWA ELECTRIC SIEP C710617 05F YASKAWA AC Drive GA700 Technical Manual 93
Model Terminals
Recommended
Gauge
mm
2
Applicable
Gauge
(IP20
Applicable
Gauge
*1
)
mm
2
Wire
Stripping
Length
*2
mm
Terminal Screw
Tightening
Torque
N∙m (lb.∙in.)
Size Shape
4371
R/L1, S/L2, T/L3 120 × 2P
70 - 150 × 2P
(150 × 2P)
- M12 Hex self-locking nut
35
(310)
U/T1, V/T2, W/T3 120 × 2P
70 - 150 × 2P
(150 × 2P)
- M12 Hex self-locking nut
35
(310)
-, +1 120 × 2P
95 - 185 × 2P
(185 × 2P)
- M12 Hex self-locking nut
35
(310)
+3 70 × 2P
50 - 95 × 2P
(-)
- M12 Hex self-locking nut
35
(310)
120
120 - 240
(-)
- M12 Hex bolt (slotted)
32 - 40
(283 - 354)
4389
R/L1, S/L2, T/L3 120 × 2P
70 - 150 × 2P
(150 × 2P)
- M12 Hex self-locking nut
35
(310)
U/T1, V/T2, W/T3 120 × 2P
70 - 150 × 2P
(150 × 2P)
- M12 Hex self-locking nut
35
(310)
-, +1 120 × 2P
95 - 185 × 2P
(185 × 2P)
- M12 Hex self-locking nut
35
(310)
+3 95 × 2P
50 - 95 × 2P
(-)
- M12 Hex self-locking nut
35
(310)
95
35 - 240
(-)
- M12 Hex bolt (slotted)
32 - 40
(283 - 354)
4453
R/L1, S/L2, T/L3
R1/L11, S1/L21, T1/
L31
120 × 4P
70 - 150 × 4P
(150 × 4P)
- M12 Hex self-locking nut
35
(310)
U/T1, V/T2, W/T3 95 × 4P
70 - 150 × 4P
(120 - 150 × 4P)
- M12 Hex self-locking nut
35
(310)
-, +1 95 × 4P
95 - 185 × 4P
(185 × 4P)
- M12 Hex self-locking nut
35
(310)
+3 70 × 4P
35 - 95 × 4P
(95 × 4P)
- M12 Hex self-locking nut
35
(310)
150
50 - 150
(-)
- M12 Hex bolt (slotted)
32 - 40
(283 - 354)
4568
R/L1, S/L2, T/L3
R1/L11, S1/L21, T1/
L31
120 × 4P
70 - 150 × 4P
(150 × 4P)
- M12 Hex self-locking nut
35
(310)
U/T1, V/T2, W/T3 95 × 4P
70 - 150 × 4P
(120 - 150 × 4P)
- M12 Hex self-locking nut
35
(310)
-, +1 95 × 4P
95 - 185 × 4P
(185 × 4P)
- M12 Hex self-locking nut
35
(310)
+3 70 × 4P
35 - 95 × 4P
(95 × 4P)
- M12 Hex self-locking nut
35
(310)
95 × 2P
60 - 150
(-)
- M12 Hex bolt (slotted)
32 - 40
(283 - 354)
