12-18 IM 701450-01E
Explanation
Setup Data That Are Saved
The setup data existing at the time the store operation is executed can be saved.
However, setup data such as the date/time, communications, and SCSI ID numbers is
not saved.
Data Size
The size of the setup data is approximately 47 KB. However, if GO/NO-GO
determination is performed using zones (see section 10.9), 4 KB of data is added for
each registered zone.
Storage Medium and Directory
Storage media to and from which saving and loading are possible are displayed on the
File List window.
Display Examples of Storage Media
FD Floppy disk
ZIP Zip disk
PC_Card PC card
SCSI5 SCSI device with the ID number set to 5*
SCSI5-1 Partition 1 of a SCSI device whose ID number is 5*
NetWork Network drive (when the Ethernet interface option is installed)
USB USB storage
* When a SCSI device whose ID number is 5 is connected
Auto Naming
When Auto Naming is turned ON, files with a four digit number from 0000 to 2499 are
automatically created when saving the data. You can specify a common name (up to ten
characters, specified through Filename) that is placed before the number.
File Name and Comment
•A file name must be assigned. Comments are optional.
• You cannot save data to a file name that already exists in the same directory
(overwriting not allowed).
Number and types of characters that can be used
Item Number of Characters Characters That Can Be Used
File name 1 to 14 characters 0 to 9, A to Z, %, _, ( , ), -
Comment 0 to 25 characters All characters (including spaces)
Extension
The .SET extension is automatically added to the file name.
Specifying the File to Be Displayed on the File List Window
Specify the type of files to be displayed.
*.SET
Displays only setup data files.
*.*
Displays all the files in the directory.
12.7 Saving/Loading the Setup Data
To Next Page
