13-26 IM 701450-01E
Using the Web Server Function
Using the FTP Server Function (on a Web Browser)
Before using this function, check that the communication interface of the DL7400 is set
to Network (see page 13-21).
Click the FTP icon on the Web server window. A window for viewing the storage media
of the DL7400 (storage media view window) appears.
If the window does not appear, click the Refresh button on the Web browser. A login
dialog box opens. Log in. The storage media view window appears.
Web server window
Window for Viewing the Storage Media
Built-in storage media
Depending on the product specifications,
one of the following is displayed.
• Fd: Floppy disk
• Zip: Zip disk
• PC Card: PC card
• You can open folders on each storage medium and view the file list.
• You can select the files displayed in the window and transfer them to the PC.
Note
• Up to two PCs can log into the file transfer function simultaneously.
• You cannot manipulate the files simultaneously from two PCs.
• When the DL7400 is printing or operating on files (file operation from the front panel key or
file transfer using the FTP server function), the Web server function cannot be used.
• To use the FTP server on a Web browser, a network user account on the DL7400 must be
configured. For the procedure of setting user accounts, see steps 1 to 6 in section 13.6.
• An authentication login dialog box may appear on the Web browser when the FTP icon on the
Web server window is clicked. If it does, enter the user name and password that were
entered in section 13.6.
13.7 Using the Web Server Function
