VP - 6.1 Mixing Head Position Check
3 - 79
3
Search
Book TOC
Go Back
e. Place strai
g
ht ed
g
e on platen a
g
ainst Beam Block and confirm Mixin
g
Assembly is parallel
with the strai
g
ht ed
g
e (Fi
g
ure 3-37).
• If OK,
g
o to Step 2, Pa
g
e 3-80, Mix Head Ali
g
nment Check.
• If not OK,
g
o to “VP - 6.2 Mixin
g
Head Position Adjustment” (Pa
g
e 3-85).
Figure 3-37 Mixing Head Vertical Check
Platen Surface
SL-241
Ensure Paddle
is Parallel to
Ruler
Beam
Block
Ruler or
Straightedge
