6241A/6242 DC Voltage Current Source/Monitor Operation Manual
4.2.6 MENU Key (Parameter Setting)
4-8
Period Sets the following period time (Tp).
• DC source mode auto-sampling-period
• Pulse source period
• Sweep source 1step-period
A.Rng Delay Sets the wait time (Tar) after changing the range for the mea-
suremnt auto range.
MEASURE Settings for measurement.
Auto Zero Switches the measurement auto zero function ON or OFF.
On: Corrects measurement zeropoint drift approximately
every 10 seconds. The AZ indicator turns on.
Off: Turns the auto zero function OFF. The AZ indicator
turns off.
Integ Time Sets the measurement integration time.
Integration time: Select from 100 µs; 500 µs; 1 ms; 5 ms; 10 ms;
1 PLC; 100 ms; 200 ms, or S/H. S/H is sample hold mode. The
integration time becomes 100 µs. Sample hold mode (S/H) can be
set only if the source mode is Pulse mode or Pulse Sweep mode.
The set value is displayed by combining F, M, S, and L indicators
as follows.
Integration time
set
Indicator
F MS L
S/H Blink
100 μsHalf
500 μsFull
1 ms Half
5 ms Full
10 ms Half
1 PLC Full
100 ms Half
200 ms Full
Blink: indicator blinks with full-brightness
Half: indicator illuminates on with half-brightness
Full: indicator illuminates on with full-brightness
