6241A/6242 DC Voltage Current Source/Monitor Operation Manual
6.7.3 Remote Command List
6-27
Source
Time parameter SP
Th,Td,Tp[,T
w]
Th: Hold time
3 ms
Td: Measurement delay time
Unit: ms
4 ms
Tp: Period
Tw can be omitted.
50 ms
Tw : Pulse width
25 ms
SP? Response: SP<Th>,<Td>,<Tp>,<Tw>
Th,Td,Tp,Tw:<d.dddd>
*1
SD Tds Tds: Source delay time (Unit: ms)
0.03 ms
SD? Response: SDd.dddd
*1
Response FL0 SLOW
FL1 FAST
FL? Response: FL0 or FL1
Sweep
Linear Sweep
SN
[±
st, ± sp,
step]
st: Start value
0.01 mV/
0.001 µA
sp: Stop value
1 mV/
0.1 µA
step: Step value (ignores the polarity)
0.01 mV/
0.001 µA
If all the settings are omitted, set Sweep type only.
However it is not allowed to omit each value separately.
SN? Response: SN ± <st>, ± <sp>, <step>
*1
st,sp,step: <d.ddddE ± d>
Fixed level sweep SF [± lvl,
cnt]
lvl: Level source value
0 V/0 A
cnt: Number of samplings (1 to 8000)
1
If all the settings are omitted, set Sweep type only.
However it is not allowed to omit each value separately.
SF? Response: SF ± <lvl>,<cnt>
*1
lvl: <d.ddddE ± d>
cnt: <dddd>
Random sweep SC [st,sp] st: Start address (0 to 7999)
0
*3
sp: Stop address (0 to 7999)
0
If all the settings are omitted, set Sweep type only.
However it is not allowed to omit each value separately.
SC? Response: SCst,sp
st,sp:<dddd>
*1: The response decimal point is different depending on the set value.
For the source value, limit value, and time parameter set up range, refer to the performance specifications.
*3: The values can be changed only between the start and stop address that was set while it is in the Standby status.
Item Command Description
Default Operation
Power
ON
Default
setting
During DC/
pulse
operation and
suspension
During
sweep
operation and
suspension
{
