6241A/6242 DC Voltage Current Source/Monitor Operation Manual
2.1.2 Screen Display (Annotations)
2-10
10. TpALM indicator: Period becomes longer than Tp.
Longer because of source auto range;
Longer because of measurement auto range;
Longer because of measurement auto zero;
Measurement time is longer than Tp.
11. Right status Indicators
RMT : Remote control status.
MA: GPIB talker or listener.
SRQ: SRQ is being transmitted.
MAX, MIN, AVE, :
Max/Min calculations are ON.
σ: (Not in use)
ERR: Error log is generated.
CAL: Calibration mode is ON.
OPR: Illuminates or extinguishes depending on the following
operating status:
In operation: ON
In suspension: Blinks
In standby: OFF
: When the Comparator calculation is ON, either one of
these three indicators illuminates depending on the
results.
LMT: Value is at limiter status.
OSC: (Not in use)
RVS: (Not in use)
BUSY: (Not in use)
SHIFT: The 6241A/6242 is in shift mode status.
