6241A/6242 DC Voltage Current Source/Monitor Operation Manual
2.2.2 Setting Limiter Value
2-22
3. Press or rotate one click clockwise.
The range increases by one step, and the LL value also changes at the same time.
The LL value cannot be changed directly.
Separate setting
1. Press LIMIT.
The cursor positions on HL value, and LL value is displayed at half-brightness.
2. Press or rotate one click clockwise.
Only the HL value changes.
Cursor (blinking)
Half-brightness
Cursor (blinking)
Half-brightness
To Next Page
