6241A/6242 DC Voltage Current Source/Monitor Operation Manual
2.2.5 DC Measurement
2-38
10. Use or to return the source value to +2 V, and then press 123..., 4 and
ENTER in order.
The voltage-source value is set to 4 V in 30 V/6 V range.
Because the limiter restricts the source current, the limiter indicator turns on.
(See Point D in Figure 2-15)
Current-source (ISVM)
11. Press VS/IS.
The setting changes to the current-source and sets Suspend status.
12. Press 123..., 2, UNIT , and ENTER, OPR in order.
Cursor (blinking)
Blinking
Cursor (blinking)
To Next Page
