Agilent Technologies 35670A User Manual

Measuring
Structures
All structures have natural frequencies of resonance. A type of modal testing
known as the frequency response function measures the input excitation and
output response simultaneously. See figure 2-1.
The method is based on an assumption that the system under-test is linear
and stable.
Figure 2-1.
System Block Diagram
This chapter introduces some of the Agilent 35670A’s measurement capability
for measuring structures. Additional information is available in Agilent 35288,
DSA Concept Documentation or Agilent Technologies, Inc.’s application note,
AN243-3,
The Fundamentals of Modal Testing (available from your local Agilent
Technologies, Inc. Sales/Service Office).
Agilent 35670A
Measuring Structures Operator's Guide
2-2
