4 Specify the triggering and averaging parameters.
Press [
Trigger
][
CHANNEL 1 2 3 4
] to highlight 1.
Press [
TRIGGER SETUP
][
CHANNEL LEVEL
]<number>[
PERCENT %
].
or
Press <number> <unit>.
Press [
CHANNEL 1 DELAY
][
+/-
] <number> <unit>.
Press [
CHANNEL 1 2 3 4
] to highlight 2.
Press [
CHANNEL 2 DELAY
][
+/-
] <number> <unit>.
Press [
Avg
], then press [
AVERAGE ON OFF
] to highlight ON.
Press [
AVERAGE PREVIEW
][
MANUAL PREVIEW
].
5 Configure the display.
Press [
Disp Format
][
UPPER LOWER
].
Press [
Active Trace
][
A
].
Press [
Trace Coord
][
DB MAGNITUDE
].
Press [
Scale
], then press[
AUTOSCALE ON OFF
] to highlight ON.
Press [
Avg
][
AVERAGE PREVIEW
].
6 Measure the DUT.
Press [
Start
].
Do a hammer tap.
When the message “WAITING FOR ACCEPT/REJECT” appears,
press [
ACCEPT TIME REC
]
or
press [
REJECT TIME REC
].
Agilent 35670A
Operator's Guide Measuring Structures
2-15
