READ
READ:CTXSpurious[:ALL]?
Function Initiates and fetches the TX spurious emission measurement as a sequential operation.
FER measurement results are returned in the following order: integrity,TX spurious emission
pass/fail result, lower adjacent channel (-0.885 or -1.25 MHz) average spurious emissions, upper
adjacent channel (+0.885 or +1.25 MHz) average spurious emissions, lower alternate channel
(-1.98 MHz) average spurious emissions, upper alternate channel (+1.98 MHz) average spurious
emissions.
Query Integrity
• Range: 0 to 23 see “Integrity Indicator”
• Resolution: 1
TX spurious emissions pass/fail result
• Range: 0 to 1 (0 = passed, 1 = failed), 9.91 E+37
Lower adjacent channel spurious emissions
• Range: 0.00 to -70.00 dBc, 9.91 E+37
• Resolution: 0.01 dBc
Upper adjacent channel spurious emissions
• Range: 0.00 to -70.00 dBc, 9.91 E+37
• Resolution: 0.01 dBc
Lower alternate channel spurious emissions
• Range: 0.00 to -70.00 dBc, 9.91 E+37
• Resolution: 0.01 dBc
Upper alternate channel spurious emissions
• Range: 0.00 to -70.00 dBc, 9.91 E+37
• Resolution: 0.01 dBc
