RFANalyzer
RFANalyzer:MANual:ANALog:POWer:CELLular
RFANalyzer:MANual:MEASurement[:MFRequency]
Function Sets/queries the expected power when the mobile is on a cellular band (800 MHz) analog voice
channel.
Setting Range: -60 dBm to +53 dBm (interacts with the Amplitude Offset setting to determine the
available range)
Resolution: 0.01 dBm
Query Range: -60 dBm to +53 dBm
*RST setting 13 dBm
Programming Example
OUTPUT 714;”RFANalyzer:MANual:ANALog:POWer:CELLular 24 DBM”
Function The setting form of this command performs two functions: (1) sets the Meas Frequency of the test
set’s measurement signal path, and (2) selects manual (auto off) tune mode for the test set’s
measurement signal path. (See “Block Diagram” .)
The query form of this command returns the tune frequency of the test set’s measurement signal
path.
The tune mode for the test set’s measurement signal path can be returned to auto using the
“RFANalyzer:CONTrol:MEASurement:FREQuency:AUTO” command.
Setting Range: 292.5 MHz to 2700 MHz
Resolution: 0.1 Hz
Query Range: 292.5 MHz to 2700 MHz
*RST setting 896 MHz
Programming Example
OUTPUT 714;"RFANALYZER:MANUAL:MEASUREMENT:MFREQUENCY 942.6 MHZ"
!Enables manual control of the measurement signal path tune frequency and sets the tune frequency
to 942.6 MHz.
