RFANalyzer
RFANalyzer:MANual:MEASurement:FREQuency
Function Sets/queries Meas Frequency, the measurement downconverter signal path frequency control
mode. (See “Block Diagram” .)
This setting is applied when manual mode is selected (see
“RFANalyzer:CONTrol:MEASurement:FREQuency:AUTO” ).
Setting Range: 292.5 MHz to 2700 MHz
Resolution: 0.1 Hz
Query Range: 292.5 MHz to 2700 MHz
*RST setting 896 MHz
Programming Example
OUTPUT 714;"RFANALYZER:MANUAL:MEASUREMENT:FREQUENCY 942.6 MHZ"
!Sets the measurement signal path tune frequency to 942.6 MHz when manual control mode is used.
