552
Chapter 16
S
pecifications and Supplementa
l Information
General Information
Figure 16-2
Dimensions (front view
, E5071B
with Option 313, in millimeters, nominal)
Figure 16-3
Dimensions (front view
, E5071B
with Option 213, in millimeters, nominal)
557
559
