Table 16-19 Analyzer Environment and Dimensions
Description Supplemental Information
Operating Environment
Temperature +5 °C to +40 °C
Error-Corrected Temperature Range 23 °C ± 5 °C with < 1°C deviation from calibration temperature
Humidity 20% to 80% at wet bulb temperature < +29 °C (non-condensing)
Altitude 0 to 2,000 m (0 to 6,561 feet)
Vibration 0.21 G maximum, 5 Hz to 500 Hz
Non-Operating Storage Environment
Temperature −10 °C to +60 °C
Humidity 20% to 90% at wet bulb temperature < +40 °C (non-condensing)
Altitude 0 to 4,572 m (0 to 15,000 feet)
Vibration 0.5 G maximum, 5 Hz to 500 Hz
Dimensions See Figure 16-1 through Figure 16-5.
Weight (Net) 17.5 kg (Option 213/214, nominal)
19.5 kg (Option 413/414, nominal)
Chapter 16 551
Specifications and Supplemental Information
General Information
16. Specifications and
Supplemental Information
Figure 16-1 Dimensions (front view, E5071B with Option 413, in millimeters, nominal)
