Agilent Technologies ENA Series

656 Appendix D
Softkey Functions
Analysis Menu
(Continued)
Fixture Simulator
De-Embedding S4P
Topology
Ports
3-2-4
*2
Sets the ports of the analyzer connected to ports a, b, and c in Figure 7-6 to
test ports 3, 2, and 4, respectively.
:CALC{1-16}:FSIM:EMB:TOP:B:PORT
3,2,4
3-4-1
*2
Sets the ports of the analyzer connected to ports a, b, and c in Figure 7-6 to
test ports 3, 4, and 1, respectively.
:CALC{1-16}:FSIM:EMB:TOP:B:PORT
3,4,1
3-4-2
*2
Sets the ports of the analyzer connected to ports a, b, and c in Figure 7-6 to
test ports 3, 4, and 2, respectively.
:CALC{1-16}:FSIM:EMB:TOP:B:PORT
3,4,2
4-1-2
*2
Sets the ports of the analyzer connected to ports a, b, and c in Figure 7-6 to
test ports 4, 1, and 2, respectively.
:CALC{1-16}:FSIM:EMB:TOP:B:PORT
4,1,2
4-1-3
*2
Sets the ports of the analyzer connected to ports a, b, and c in Figure 7-6 to
test ports 4, 1, and 3, respectively.
:CALC{1-16}:FSIM:EMB:TOP:B:PORT
4,1,3
4-2-1
*2
Sets the ports of the analyzer connected to ports a, b, and c in Figure 7-6 to
test ports 4, 2, and 1, respectively.
:CALC{1-16}:FSIM:EMB:TOP:B:PORT
4,2,1
4-2-3
*2
Sets the ports of the analyzer connected to ports a, b, and c in Figure 7-6 to
test ports 4, 2, and 3, respectively.
:CALC{1-16}:FSIM:EMB:TOP:B:PORT
4,2,3
4-3-1
*2
Sets the ports of the analyzer connected to ports a, b, and c in Figure 7-6 to
test ports 4, 3, and 1, respectively.
:CALC{1-16}:FSIM:EMB:TOP:B:PORT
4,3,1
4-3-2
*2
Sets the ports of the analyzer connected to ports a, b, and c in Figure 7-6 to
test ports 4, 3, and 2, respectively.
:CALC{1-16}:FSIM:EMB:TOP:B:PORT
4,3,2
Cancel Returns to the softkey display screen one level higher.
Ports
*2
Displays the softkey to select a port of the analyzer (test port) that you want to connect to the DUT. (When you
select
A on the Select Topology menu.)
1-2-3-4 Sets the ports of the analyzer connected to ports a, b, c and d in Figure 7-6
to test ports 1, 2, 3, and 4, respectively.
:CALC{1-16}:FSIM:EMB:TOP:C:POR
T 1,2,3,4
1-2-4-3 Sets the ports of the analyzer connected to ports a, b, c and d in Figure 7-6
to test ports 1, 2, 4, and 3, respectively.
:CALC{1-16}:FSIM:EMB:TOP:C:POR
T 1,2,4,3
1-3-2-4 Sets the ports of the analyzer connected to ports a, b, c and d in Figure 7-6
to test ports 1, 3, 2, and 4, respectively.
:CALC{1-16}:FSIM:EMB:TOP:C:POR
T 1,3,2,4
1-3-4-2 Sets the ports of the analyzer connected to ports a, b, c and d in Figure 7-6
to test ports 1, 3, 4, and 2, respectively.
:CALC{1-16}:FSIM:EMB:TOP:C:POR
T 1,3,4,2
1-4-2-3 Sets the ports of the analyzer connected to ports a, b, c and d in Figure 7-6
to test ports 1, 4, 2, and 3, respectively.
:CALC{1-16}:FSIM:EMB:TOP:C:POR
T 1,4,2,3
1-4-3-2 Sets the ports of the analyzer connected to ports a, b, c and d in Figure 7-6
to test ports 1, 4, 3, and 2, respectively.
:CALC{1-16}:FSIM:EMB:TOP:C:POR
T 1,4,3,2
2-1-3-4 Sets the ports of the analyzer connected to ports a, b, c and d in Figure 7-6
to test ports 2, 1, 3, and 4, respectively.
:CALC{1-16}:FSIM:EMB:TOP:C:POR
T 2,1,3,4
2-1-4-3 Sets the ports of the analyzer connected to ports a, b, c and d in Figure 7-6
to test ports 2, 1, 4, and 3, respectively.
:CALC{1-16}:FSIM:EMB:TOP:C:POR
T 2,1,4,3
2-3-1-4 Sets the ports of the analyzer connected to ports a, b, c and d in Figure 7-6
to test ports 2, 3, 1, and 4, respectively.
:CALC{1-16}:FSIM:EMB:TOP:C:POR
T 2,3,1,4
2-3-4-1 Sets the ports of the analyzer connected to ports a, b, c and d in Figure 7-6
to test ports 2, 3, 4, and 1, respectively.
:CALC{1-16}:FSIM:EMB:TOP:C:POR
T 2,3,4,1
2-4-1-3 Sets the ports of the analyzer connected to ports a, b, c and d in Figure 7-6
to test ports 2, 4, 1, and 3, respectively.
:CALC{1-16}:FSIM:EMB:TOP:C:POR
T 2,4,1,3
2-4-3-1 Sets the ports of the analyzer connected to ports a, b, c and d in Figure 7-6
to test ports 2, 4, 3, and 1, respectively.
:CALC{1-16}:FSIM:EMB:TOP:C:POR
T 2,4,3,1
Key Operation Function SCPI Command
