658 Appendix D
Softkey Functions
Analysis Menu
(Continued)
Fixture Simulator
De-Embedding S4P
Topology
Type (nwk2)
De-Embed Select de-embedding.
:CALC{1-16}:FSIM:EMB:NETW2:TYP
E DEEM
Cancel Returns to the softkey display screen in one level higher.
User File
(nwk2)
Opens the dialog box to read in a 4 port touchstone data file that the user
prepared for the network 2. You can embed/de-embed the network read in
here.
:CALC{1-16}:FSIM:EMB:NETW2:FIL
Return Returns to the softkey display screen one level higher.
Return Returns to the softkey display screen one level higher.
Return Returns to the softkey display screen one level higher.
Gating Displays softkeys for setting up the gating function of the time domain function.
Gating Enables or disables the gating function.
:CALC{1-16}:FILT:TIME:STAT
Start Sets the start value of the gate.
:CALC{1-16}:FILT:TIME:STAR
Stop Sets the stop value of the gate.
:CALC{1-16}:FILT:TIME:STOP
Center Sets the center value of the gate.
:CALC{1-16}:FILT:TIME:CENT
Span Sets the span value of the gate.
:CALC{1-16}:FILT:TIME:SPAN
Type Sets a type of the gate (bandpass/notch).
:CALC{1-16}:FILT:TIME:SPAN
Shape Displays softkeys for selecting a shape of the gate.
Maximum Selects the maximum shape.
:CALC{1-16}:FILT:TIME:SHAP MAX
Wide Selects the wide shape.
:CALC{1-16}:FILT:TIME:SHAP WIDE
Normal Selects the normal shape.
:CALC{1-16}:FILT:TIME:SHAP NORM
Minimum Selects the minimum shape.
:CALC{1-16}:FILT:TIME:SHAP MIN
Cancel Returns to the softkey display screen one level higher.
Return Returns to the softkey display screen one level higher.
Transform Displays softkeys for setting up the transform function of the time domain function.
Transform Enables or disables the transform function.
:CALC{1-16}:TRAN:TIME:STAT
Start Sets the start value.
:CALC{1-16}:TRAN:TIME:STAR
Stop Sets the stop value.
:CALC{1-16}:TRAN:TIME:STOP
Center Sets the center value.
:CALC{1-16}:TRAN:TIME:CENT
Span Sets the span value.
:CALC{1-16}:TRAN:TIME:SPAN
Set Freq Low Pass Changes the frequency range to match with the low-pass type
transformation.
:CALC{1-16}:TRAN:TIME:LPFR
Type Displays softkeys for selecting a type of the transform.
Bandpass Selects the bandpass mode.
:CALC{1-16}:TRAN:TIME BPAS
Lowpass Step Selects the lowpass step mode. :CALC{1-16}:TRAN:TIME LPAS
:CALC{1-16}:TRAN:TIME:STIM STEP
Lowpass Imp Selects the lowpass impulse mode. :CALC{1-16}:TRAN:TIME LPAS
:CALC{1-16}:TRAN:TIME:STIM STEP
Cancel Returns to the softkey display screen one level higher.
Key Operation Function SCPI Command
