Calibrate
1-Port Cal Displays softkeys for executing 1-port calibrations.
Select Port Displays softkeys for selecting a test port.
1 Selects test port 1.
:SENS{1-16}:CORR:COLL:METH:SOLT1 1
2 Selects test port 2.
:SENS{1-16}:CORR:COLL:METH:SOLT1 2
3
*1
Selects test port 3.
:SENS{1-16}:CORR:COLL:METH:SOLT1 3
4
*2
Selects test port 4.
:SENS{1-16}:CORR:COLL:METH:SOLT1 4
Select Port
Cancel Returns to the softkey display screen one level higher.
Open Executes an OPEN calibration on the test port selected in the Select
Port
menu.
:SENS{1-16}:CORR:COLL:OPEN
Short Executes a SHORT calibration on the test port selected in the Select
Port
menu.
:SENS{1-16}:CORR:COLL:SHOR
Load Executes a LOAD calibration on the test port selected in the Select
Port
menu.
:SENS{1-16}:CORR:COLL:LOAD
Done Terminates a calibration process and calculates the calibration
coefficients.
:SENS{1-16}:CORR:COLL:SAVE
Cancel Displays softkeys for canceling a calibration.
OK Cancels a calibration process and clear the measurement data of
standard.
:SENS{1-16}:CORR:COLL:CLE
Cancel Returns to the softkey display screen one level higher.
Return Returns to the softkey display screen one level higher.
2-Port Cal Displays softkeys for executing a full 2-port calibration.
Select Ports
*1
Displays softkeys for selecting test ports.
1-2 Selects test ports 1 and 2.
:SENS{1-16}:CORR:COLL:METH:SOLT2 1,2
1-3 Selects test ports 1 and 3.
:SENS{1-16}:CORR:COLL:METH:SOLT2 1,3
1-4
*2
Selects test ports 1 and 4.
:SENS{1-16}:CORR:COLL:METH:SOLT2 1,4
2-3 Selects test ports 2 and 3.
:SENS{1-16}:CORR:COLL:METH:SOLT2 2,3
2-4
*2
Selects test ports 2 and 4.
:SENS{1-16}:CORR:COLL:METH:SOLT2 2,4
3-4
*2
Selects test ports 3 and 4.
:SENS{1-16}:CORR:COLL:METH:SOLT2 3,4
Cancel Returns to the softkey display screen one level higher.
Reflection Displays softkeys for executing reflection calibrations. Symbols x and y refer to the two test ports selected in the
Select Ports menu (x and y are always 1 and 2, respectively, for models with Option 213 or 214).
Port x Open Executes an OPEN reflection calibration on test port x.
:SENS{1-16}:CORR:COLL:OPEN x
Port x Short Executes a SHORT reflection calibration on test port x.
:SENS{1-16}:CORR:COLL:SHOR x
Port x Load Executes a LOAD reflection calibration on test port x.
:SENS{1-16}:CORR:COLL:LOAD x
Port y Open Executes an OPEN reflection calibration on test port y.
:SENS{1-16}:CORR:COLL:OPEN y
Port y Short Executes a SHORT reflection calibration on test port y.
:SENS{1-16}:CORR:COLL:SHOR y
Port y Load Executes a LOAD reflection calibration on test port y.
:SENS{1-16}:CORR:COLL:LOAD y
Return Returns to the softkey display screen one level higher.
