684 Appendix D
Softkey Functions
Calibration Menu
(Continued)
Power Calibration Displays the softkey to execute the power calibration.
Sensor B Settings Displays the softkey to set the calibration coefficient for the power sensor connected to channel B.
Ref Cal Factor Sets the value of the reference calibration coefficient.
:SOUR:POW:PORT:CORR:COLL:BSEN:RCF
Delete Deletes the cursor line on the calibration coefficient table.
:SOUR:POW:PORT:CORR:COLL:TABL:BSEN:
DATA
Add Inserts a new segment above the cursor line on the calibration
coefficient table.
:SOUR:POW:PORT:CORR:COLL:TABL:BSEN:
DATA
Clear Loss Table Displays the softkey to clear the calibration coefficient table.
OK Deletes all segments in the calibration coefficient table. None
Cancel Returns to the softkey display in one level higher.
Export to CSV
File
Exports (writes in another software format) the content of the
calibration coefficient table as a CSV (comma separated value)
format file.
:MMEM:STOR:BSCF
Import from CSV
File
Imports a saved CSV (comma separated value) format file into the
calibration coefficient table.
:MMEM:LOAD:BSCF
Return Returns to the softkey display one level higher.
Return Returns to the softkey display screen one level higher.
Receiver Calibration Displays the softkey to execute the receiver calibration.
Select Port Displays the softkey to select the test port you want to calibrate.
1 Selects test port 1. None
2 Selects test port 2. None
3 Selects test port 3. None
4 Selects test port 4. None
Cancel Returns to the softkey display screen one level higher.
Correction Enables or disables error correction.
:SENS{1-16}:CORR:REC{1-4}
Source Port Displays the softkey to select the source port you want to use for receiver calibration.
1 Selects test port 1 as the source port. None
2 Selects test port 2 as the source port. None
3 Selects test port 3 as the source port. None
4 Selects test port 4 as the source port. None
Cancel Returns to the softkey display screen one level higher.
Take Cal Sweep Executes the measurement of receiver calibration data.
:SENS{1-16}:CORR:REC{1-4}:COLL:ACQ
Return Returns to the softkey display screen one level higher.
Key Operation Function SCPI Command
