Softkey Functions
Sweep Setup Menu
(Continued)
Sweep Type
Cancel Returns to the softkey display screen one level higher.
Edit Segment Table Displays the segment sweep setup table as well as softkeys for editing the segment table.
Freq Mode Alternates the setup mode for the sweep range between two methods: one
using the starting and ending frequencies (
Start/Stop), and the other using
the center frequency and a frequency span (
Center/Span).
:SENS{1-16}:SEGM:DATA
List IFBW Enables or disables the IF bandwidth display in the segment table.
:SENS{1-16}:SEGM:DATA
List Power Enables or disables the power level display in the segment table.
:SENS{1-16}:SEGM:DATA
List Delay Enables or disables the segment delay display in the segment table.
:SENS{1-16}:SEGM:DATA
List Sweep Mode Enables or disables the segment sweep mode display in the segment table.
:SENS{1-16}:SEGM:DATA
List Time Enables or disables the segment sweep time display in the segment table.
:SENS{1-16}:SEGM:DATA
Delete Deletes from the segment table the segment upon which the cursor is
currently located. If the cursor is not displayed, the segment on the bottom
will be deleted.
:SENS{1-16}:SEGM:DATA
Add Adds a new segment immediately above the segment upon which the cursor
is currently located. If the cursor is not displayed, a new segment will be
added to the bottom of the table.
:SENS{1-16}:SEGM:DATA
Clear Segment
Table
Displays softkeys for clearing elements of the segment table.
OK Deletes all segments in the segment table. None
Cancel Returns to the softkey display screen one level higher.
Export to CSV File Exports (saves data in file formats used by other software) the segment
table as a CSV (comma-separated value) file.
:MMEM:STOR:SEGM
Import from CSV
File
Imports (loads a file that is written in a format used by other software) a
CSV (comma-separated value) file to the segment table of
E5070B/E5071B.
:MMEM:LOAD:SEGM
Return Returns to the softkey display screen one level higher.
Segment Display Selects linear frequency (Freq Base) or selects the order of measurements
(1, 2, ..., N; where N refers to the number of points) (
Order Base) for
drawing the X-axis of a rectangular display format in a segment sweep.
:DISP:WIND{1-16}:X:SPAC LIN
:DISP:WIND{1-16}:X:SPAC OBAS
Frequency Offset Displays the softkey to setup the frequency offset.
Frequency Offset Turns on/off of the frequency offset feature.
:SENS{1-16}:OFFS
Port 1 Displays the softkey to setup the frequency offset parameter for test port 1.
Multiplier
Set the muliplier of the base frequency
*2
.
:SENS{1-16}:OFFS:PORT{1-4}:MULT
Divisor
Set the divisor of the base frequency
*2
.
:SENS{1-16}:OFFS:PORT{1-4}:DIV
Offset
Set the offset for the base frequency
*2
.
:SENS{1-16}:OFFS:PORT{1-4}:OFFS
Start Set the start frequency.
:SENS{1-16}:OFFS:PORT{1-4}:STAR
Stop Set the stop frequency.
:SENS{1-16}:OFFS:PORT{1-4}:STOP
Return Returns to the softkey display screen one level higher.
Port 2
to
Port 4
Displays the softkey to setup the frequency offset parameters for test port 2 to 4. Lower level softkeys are the same
as the
Port 1.
External Source Displays the softkey to setup the external signal source.
LO Frequency Set the external signal source frequency.
:SENS{1-16}:OFFS:LOC:STAT
Multiplier
Set the muliplier of the base frequency
*2
.
:SENS{1-16}:OFFS:LOC:MULT
Divisor
Set the divisor of the base frequency
*2
.
:SENS{1-16}:OFFS:LOC:DIV
Key Operation Function SCPI Command
